New Metal Wall Panel Lets You Unleash Your Creativity

ATAS New Metal Wall Panel
June 24, 2022 at 6:00 a.m.

By ATAS International.

The High Design Wall Flush V offers a number of design choices with more mix and match panels available to create unique patterns.

Introducing a new profile to ATAS’ Design Wall™ System. Design Wall is a structural panel with optional louvered style venting.  The four profile options are now joined by a fifth style of panel, the new High Design Wall Flush V (DSV120) panel. This panel offers a distinctive vee shaped profile and can be installed horizontally and vertically.  It is available in aluminum, steel, zinc, and copper, offers 12” coverage, and has a maximum length of 26’-0”.

Allowing for design creativity, Design Wall panels can be mixed and matched within their own series to achieve unique patterns across a façade, whether in the same color, or with complementary or contrasting colors.  The aluminum panels can be perforated in any of our six standard patterns, or in a custom pattern.  The perforated panels are ideal for numerous applications including architectural design, passive solar shading, ventilation, acoustical solutions, and equipment screens.  ATAS can color-match each side of a perforated panel for applications where both sides are visible.  The aluminum substrate is ideal for outdoor perforated applications due to its inherent corrosion-resistant properties.

High Design Wall Flush V panels are manufactured in over 40 stock 70% PVDF finishes, Oxide Series and Woodland Series 70% PVDF print coats, as well as in Clear Satin and Dark Bronze anodized aluminum.  Custom colors can be achieved on coil coated metal, dependent upon quantities.  Post-painted options are offered for small quantities and in custom colors.  Smooth and stucco embossed textures are available on the panels, along with a complete line of trims in matching colors, gauges, and finishes, or as specified.  Wood grain embossing is available on the DWF, DWH, and DSV profiles, in either 24-gauge steel or .032 and .040 aluminum.  The aesthetics of High Design Wall Flush V can be enhanced by using factory fabricated Elite Series accessories, including Z Boxes, Snap J and H channels, closure angles, extrusions, and mitered corners.

Have a question? AskARoofer

Find your local roofing contractor in the RoofersCoffeeShop® Contractor Directory.

Original article source: ATAS International
